DF-490
HEE
Cast steel closed chock is a fixed deck mooring fitting widely installed on ship bulwark or deck edge. It guides mooring ropes and steel wires while restraining the cable during berthing. This closed chock features enclosed double curved arch design. The smooth rounded inner profile reduces sharp edges, greatly lowering abrasion and fatigue damage to mooring lines and wire ropes. Manufactured by cast steel process, it delivers high tensile strength and impact resistance under heavy mooring loads. Available in a full range of sizes and working load limits. Surface can be supplied as raw casting, primer painted or hot-dip alvanized. Material test certificates are available for shipyard newbuilding and vessel refit orders.
Product Name: Heavy-Duty Cast Steel Closed Chock
Type: Closed mooring chock / closed fairlead chock
Material: Cast steel (ZG270-500 or equivalent marine cast steel)
Structure: Double arch closed design with integrated base plate
Surface finish: Raw casting / primer paint / hot-dip galvanized
Application: Ship deck mooring, vessel berthing, mooring line guiding
Optional: Material MTC, custom size
Design schematic and technical parameters
MODEL NO. | A | B | C | D | E | WT.(lbs) |
DF-497 | 19 3/4" | 8" | 4" | 6 3/4" | 6" | 84 |
DF-480 | 27 3/4" | 12" | 6" | 10 1/8" | 9" | 191 |
DF-490 | 36" | 16" | 8" | 13 3/8" | 12" | 455 |
Cargo ships, bulk carriers, tankers, barges, fishing vessels
Offshore work boats, port pontoons and floating platforms
Ship new construction, shipyard repair and retrofit projects
Harbour mooring systems
A: Closed chock is a marine mooring fitting mounted on deck or bulwark. Its enclosed double arch shape guides mooring lines and stops ropes slipping out under tension during vessel berthing.
A: Closed chock has fully enclosed arch loops, which prevents mooring cable from jumping out, more reliable for heavy load. Open chock is easier for quick rope threading.
A: Cast steel can withstand sudden impact and heavy tensile loads during mooring. Smooth casting contour protects mooring ropes better.
A: Yes, Mill Test Certificates (MTC) for cast steel material can be provided for bulk shipyard orders.
A: We offer raw casting, anti-rust primer painting, or hot-dip galvanizing for superior saltwater corrosion protection.
A: The chock base plate is welded directly onto ship deck or bulwark structure. Full penetration welding is required to meet marine load requirements.
A: Standard sizes in stock for fast delivery. Custom castings acceptable. Send your required working load and dimension for quotation.
